Distinctive Mobility
Ideal For

Residential Buildings

Indoor Use

Cost
$$$
Site Preparation
Low
Travel Distance
50FT
Max Capacity
1400LBS

Max Travel Speed

50FT/MIN

Max Platform Size

18 square feet
Get a Quote

KEY FEATURES

Soft Start/Stop
Thoughtful engineering means every ride on a RAM product begins and ends with comfort in mind.
Fully Counter Balanced Traction Drive
The Prism’s fully counterbalanced traction drive uses at least 50% less energy than other comparable products.
All-Electric Drive System
RAM’s field-proven counterweight electric drive system is reliable, powerful, and whisper-quiet, offering households best-in-class energy efficiency. Plus, no hydraulic fluid = no harsh smells.
Machine-Room Less (MRL) Design
While other elevators may need a separate room for essential machinery, every RAM product is compact and self-contained, saving you space, time and money.
Low Overhead Clearance
Smart space design delivers the most space-efficient traction MRL on the market. All drive components mount directly to the top of the RAM rigid guide-rail frame, fitting into a standard 96” top-floor ceiling height.
Limited or No Pit Required
Choose a pitless build with a 3” ramp, ideal for existing spaces, or a 3” pit for flush access. RAM Advantage, an essential feature found in all of our products.

PRISM IS THE BEST CHOICE FOR

Showstopping Functional Beauty. At RAM, we believe the journey is as important as the destination. Your home elevator and lift solutions shouldn’t simply be a means to an end but an integral part of your home’s aesthetic and functionality.

Expansive Elegance

Reach new heights of mobility and modern design, with RAM’s most ambitious home elevator solution yet.

Accessibility as Art

Structures with high traffic open concept living spaces are transformed with RAM’s bespoke accents and finishings.

Design, with Purpose

Conceptual yet purpose-driven, RAM doesn’t compromise performance for aesthetic function; we elevate both.

FEATURED PROJECT

At RAM Elevators + Lifts, we believe that accessibility should be seamless, stylish, and smart. Proudly engineering cutting-edge platform lifts and elevators, we’re passionate about redefining what’s possible for residential and commercial accessibility solutions. As demand grows for efficient, non-intrusive alternatives to legacy elevator technologies, RAM is leading the charge with innovative lift solutions that offer an affordable, space-conscious, and customizable option for homes and public spaces alike.
Built in North America and trusted across the continent, every RAM lift or elevator installation combines performance with simplicity—eliminating the need for complex shaftways, deep pits, or heavy construction. Whether you’re future-proofing your home, meeting accessibility codes, or creating inclusive commercial environments, our products are engineered to blend in aesthetically while standing out in performance and reliability.

Superior lifts and elevators for home and commercial spaces.

VIEW ALL PROJECTS
Uncompromisingly Sophisticated Infill
This home is part of an infill project in a mature central neighourhood. The elevator was added to give homeowners unfettered access while maximizing vertical space. Its understated design and four-stops with three entry points minimizes the product’s footprint while maximizing impact, ushering riders (and their furry friends) from the basement garage all the way to a rooftop deck, stopping in the kitchen, and bedroom levels along the journey.
Accessibility Takes Centre Stage
This commercial elevator is no wallflower. Designed with a staircase wrapping around it, and made fully of glass, riders get a 270 degree view of the stunning golf course that surrounds it. When faced with an accessibility challenge, our client chose to lean-in to the aesthetic potential of our products and created a truly wow-ing experience for those who need, or simple chose to ride in style in this two storey multipurpose building which houses a pro-shop, meeting spaces and a café.
Creating Freedom at Home
After an accident left our client in a wheelchair, he was suddenly cut off from many of the day-to-day aspects of life at home. When his family made the decision to build a new home, the goal was designing a space that allowed everyone to be together in every space. This fully accessible new build includes a discrete three stop elevator that connects the walk-out basement, the main floor living space, and the third floor bedroom space, giving unbridled home freedom to all members of this lovely family.
Accessible Connectivity
Connecting a commercial high-rise with the municipal light rail transit system, this 4-1/2 foot vertical lift was added as a vital connective hub between two spaces. Ease of use, safety, reliability and durability were priorities for this frequently used lift, without compromising the carefully curated aesthetic of the space, or flow of adjacent foot traffic.
Refined Retrofit Capability
When our client renovated a heritage space for their new head office, they faced unique layout considerations that could cause accessibility challenges in reaching the main office space. Looking for a refined solution while integrating with the sophisticated, modern and welcoming corporate entrance aesthetic, the Commercial Stratus fit the bill and gave our client a seamless solution that didn’t break the bank, or look out of place.
French Modern Luxury
This 8,000 square foot newly built private residence is designed to impress and entertain. The elevator was designed to highlight the home’s incredible river valley views with a glass-backed car and shaft, giving riders a breathtaking vista as they ride from the basement sports court and gym to the rooftop hot tub. It’s black, white and marble finishings and custom sliding door fit seamlessly with this modern, youthful, and grand home.

FREQUENTLY ASKED QUESTIONS

FREQUENTLY ASKED QUESTIONS

We understand that installing a residential mobility solution, like an elevator or lift, is a significant financial investment. However, to guarantee our products’ safety and optimal lifecycle, they must be installed by a guaranteed RAM dealer and contractor. That’s because we ensure legal and regulatory compliance on every installation so you can enjoy a secure, durable, and reliable home mobility solution for years to come.

At RAM, we understand that your home is your sanctuary— and, likely, your most significant investment. That’s why we’ve spent decades designing and engineering residential mobility solutions to have minimal impact on a home’s structure. Our elevators and lifts are shaftless, which means they don’t require a machine room installation, meaning they are less invasive and damaging. If you’re still worried about the impact of a residential elevator installation on your home, we suggest looking at one of our residential lift options instead, which are even less invasive.
Like any other mechanical device, such as a furnace or motor, your RAM Elevator requires periodic maintenance to keep it functioning at its best. Thanks to our innovative engineering and design, though, your new residential elevator from RAM will require less frequent or invasive maintenance than a traditional elevator with a machine room and drive shaft. We’re happy to walk you through your maintenance schedule as part of our installation and onboarding process.
RAM’s residential elevator solutions can move between two to four floors, from the basement to the attic, if that’s what your home needs. However, anything more than that and we suggest looking at one of our commercial solutions, which are more robust. If you need help moving between split levels or from ground level to a porch, you may want to consider one of our residential lift solutions.

CERTIFICATIONS

At RAM Elevators + Lifts, we believe that trust is built on transparency. That’s why we proudly share the certifications, safety standards, and industry memberships that guide every product we build and every installation we support.

Unlike many large competitors in the accessibility space, RAM makes these commitments visible—because we believe our customers deserve clarity when it comes to the safety, performance, and reliability of our products. Learn more about our commitment to transparency on our Certifications and Standards page.

Technical Documentation + Support

Please check with local regulatory authorities as capacity, size and speed restrictions may apply
ASME A18.1/B355
Car Size:
Car Inside DimensionsShaft Dimensions
WidthDepthHeightDepthLength
Small36″48″84″50.5″53.5″
Medium40″54″84″54.5″59.5″
Large40″60″84″54.5″65.5″
Travel Heights:
Max Travel (T)Min Overhead Clearance (C)Tower Height (TH)
9′92″13′
11′92″15′
14′92″18′
Residential Prism Brochure
